Plane Finder is a United Kingdom-based real-time flight tracking service launched in 2009, that is able to show flight data globally. The data available includes flight numbers, how fast an aircraft is moving, its elevation and destination of travel. Several variants of the service are available as mobile apps including free, premium 3D and augmented reality versions. The flight tracking map and database can be accessed by web browsers. Plane Finder allows registered users to share their ADS-B and MLAT data via the Plane Finder ADS-B Client, available for macOS, Windows and Linux. Plane Finder supports VFR charts from NATS, and was the first major flight tracking app to introduce a replay feature, allowing users to replay flights dating back to 2011. == Flight tracking == Plane Finder collects data from its own global network of receivers, using the following sources. === Automatic dependent surveillance-broadcast (ADS-B) === A network of automatic dependent surveillance-broadcast (ADS-B) receivers gathers aircraft data such as callsign, position and speed. Plane Finder serves to supplement this data with additional information, including aircraft registration/tail number, departure airport, destination, artwork, and photographs. Plane Finder users can apply for an ADS-B receiver in exchange for their flight data. === Multilateration (MLAT) === To deliver aircraft position data where ADS-B is unavailable, Plane Finder uses multilateration (MLAT). Using three or more receivers running Plane Finder client software, monitoring the aircraft simultaneously, the aircraft’s position is calculated using receiver location and accurate timestamps. While European airspace is widely covered, only some parts of North American airspace are covered. === Federal Aviation Administration (FAA) feed === ADS-B is prevalent across Europe and Australia, but not in North America. Where MLAT or ADS-B data is unavailable, a feed from the Federal Aviation Administration provides flight information. The FAA feed covers United States and Canadian airspace, including bordering areas of the Atlantic and Pacific Oceans. === FLARM feed === Plane Finder collects data from a centralised FLARM feed, for monitoring small aircraft and gliders. == Flight data source == The Plane Finder website and database is widely used as an information source to support articles in the media. The Independent used Plane Finder flight tracking to demonstrate to readers the flight path of flight MT2706, which turned back as a result of last minute Egyptian government flight restrictions on 6 November 2015. The Independent also used Plane Finder information to demonstrate a timeline of the speed/altitude of flight 7K 9268, a Russian plane which crashed on 31 October 2015. The BBC cited Plane Finder in regard to the point at which at British Airways flight turned back to Heathrow Airport to make an emergency landing after smoke was seen coming from its engines. Plane Finder data has also been used to create original imagery for the media, such as the Washington Post, which used Plane Finder as a source to show flight patterns immediately after the Brussels bombings in March 2016.
Boundary vector field
The boundary vector field (BVF) is an external force for parametric active contours (i.e. Snakes). In the fields of computer vision and image processing, parametric active contours are widely used for segmentation and object extraction. The active contours move progressively towards its target based on the external forces. There are a number of shortcomings in using the traditional external forces, including the capture range problem, the concave object extraction problem, and high computational requirements. The BVF is generated by an interpolation scheme which reduces the computational requirement significantly, and at the same time, improves the capture range and concave object extraction capability. The BVF is also tested in moving object tracking and is proven to provide fast detection method for real time video applications.
Super-resolution imaging
Super-resolution imaging (SR) is a class of techniques that improve the resolution of an imaging system. In optical SR the diffraction limit of systems is transcended, while in geometrical SR the resolution of digital imaging sensors is enhanced. In some radar and sonar imaging applications (e.g. magnetic resonance imaging (MRI), high-resolution computed tomography), subspace decomposition-based methods (e.g. MUSIC) and compressed sensing-based algorithms (e.g., SAMV) are employed to achieve SR over standard periodogram algorithm. Super-resolution imaging techniques are used in general image processing and in super-resolution microscopy. == Super-resolution principles == Several concepts are fundamental to super-resolution imaging: Diffraction limit: the capacity of an optical instrument to reproduce the details of an object in an image has limits that are imposed by laws of physics: the diffraction equations in the wave theory of light, or the uncertainty principle for photons in quantum mechanics. Information transfer can never be increased beyond this boundary, but packets outside the limits can be cleverly swapped for (or multiplexed with) some inside it. Super-resolution microscopy does not so much “break” as “circumvent” the diffraction limit. New procedures probing electro-magnetic disturbances at the molecular level (in the so-called near field) remain fully consistent with Maxwell's equations. Spatial frequency domain: A succinct expression of the diffraction limit is given in the spatial frequency domain. In Fourier optics light distributions are expressed as superpositions of a series of grating light patterns in a range of fringe widths - these widths represent the spatial frequencies. It is generally taught that diffraction theory stipulates an upper limit, the cut-off spatial-frequency, beyond which pattern elements fail to be transferred into the optical image, i.e., are not resolved. But in fact what is set by diffraction theory is the width of the passband, not a fixed upper limit. No laws of physics are broken when a spatial frequency band beyond the cut-off spatial frequency is swapped for one inside it: this has long been implemented in dark-field microscopy. Nor are information-theoretical rules broken when superimposing several bands, disentangling them in the received image needs assumptions of object invariance during multiple exposures, i.e., the substitution of one kind of uncertainty for another. Information: When the term super-resolution is used in techniques based on the inference of object details using a statistical treatment of the image within standard resolution limits (for example, averaging multiple exposures), it involves an exchange of one kind of information (extracting signal from noise) for another (the assumption that the target has remained invariant). Recent breakthroughs incorporate quantum-transformer hybrids into super-resolution, such as QUIET‑SR, a 2025 model that employs shifted quantum window attention within a transformer to enhance image detail while respecting diffraction and information-theory limits Similarly, frequency-integrated transformers (e.g., FIT) enrich super-resolution by explicitly combining spatial and frequency-domain information via FFT-based attention, improving reconstruction across scales Resolution and localization: True resolution involves the distinction of whether a target, e.g. a star or a spectral line, is single or double, ordinarily requiring separable peaks in the image. When a target is known to be single, its location can be determined with higher precision than the image width by finding the centroid (center of gravity) of its image light distribution. The word ultra-resolution had been proposed for this process but it did not catch on, and the high-precision localization procedure is typically referred to as super-resolution. == Techniques == === Optical or diffractive super-resolution === Substituting spatial-frequency bands: Though the bandwidth allowable by diffraction is fixed, it can be positioned anywhere in the spatial-frequency spectrum. Dark-field illumination in microscopy is an example. See also aperture synthesis. ==== Multiplexing spatial-frequency bands ==== An image is formed using the normal passband of the optical device. Then, some known light structure (for example, a set of light fringes) is superimposed on the target. The image now contains components resulting from the combination of the target and the superimposed light structure, e.g. moiré fringes, and carries information about target detail which simple unstructured illumination does not. The “superresolved” components, however, need disentangling to be revealed. For an example, see structured illumination (figure to left). ==== Multiple parameter use within traditional diffraction limit ==== If a target has no special polarization or wavelength properties, two polarization states or non-overlapping wavelength regions can be used to encode target details, one in a spatial-frequency band inside the cut-off limit the other beyond it. Both would use normal passband transmission but are then separately decoded to reconstitute target structure with extended resolution. ==== Probing near-field electromagnetic disturbance ==== Super-resolution microscopy is generally discussed within the realm of conventional optical imagery. However, modern technology allows the probing of electromagnetic disturbance within molecular distances of the source, which has superior resolution properties. See also evanescent waves and the development of the new super lens. === Geometrical or image-processing super-resolution === ==== Multi-exposure image noise reduction ==== When an image is degraded by noise, the resolution may be improved by averaging multiple exposures. See example on the right. ==== Single-frame deblurring ==== Known defects in a given imaging situation, such as defocus or aberrations, can sometimes be mitigated in whole or in part by suitable spatial-frequency filtering of even a single image. Such procedures all stay within the diffraction-mandated passband, and do not extend it. ==== Sub-pixel image localization ==== The location of a single source can be determined by computing the "center of gravity" (centroid) of the light distribution extending over several adjacent pixels (see figure on the left). Provided that there is enough light, this can be achieved with arbitrary precision, very much better than pixel width of the detecting apparatus and the resolution limit for the decision of whether the source is single or double. This technique, which requires the presupposition that all the light comes from a single source, is at the basis of what has become known as super-resolution microscopy, e.g. stochastic optical reconstruction microscopy (STORM), where fluorescent probes attached to molecules give nanoscale distance information. It is also the mechanism underlying visual hyperacuity. ==== Bayesian induction beyond traditional diffraction limit ==== Some object features, though beyond the diffraction limit, may be known to be associated with other object features that are within the limits and hence contained in the image. Then conclusions can be drawn, using statistical methods, from the available image data about the presence of the full object. The classical example is Toraldo di Francia's proposition of judging whether an image is that of a single or double star by determining whether its width exceeds the spread from a single star. This can be achieved at separations well below the classical resolution bounds, and requires the prior limitation to the choice "single or double?" The approach can take the form of extrapolating the image in the frequency domain, by assuming that the object is an analytic function, and that we can exactly know the function values in some interval. This method is severely limited by the ever-present noise in digital imaging systems, but it can work for radar, astronomy, microscopy or magnetic resonance imaging. More recently, a fast single image super-resolution algorithm based on a closed-form solution to ℓ 2 − ℓ 2 {\displaystyle \ell _{2}-\ell _{2}} problems has been proposed and demonstrated to accelerate most of the existing Bayesian super-resolution methods significantly. == Aliasing == Geometrical SR reconstruction algorithms are possible if and only if the input low resolution images have been under-sampled and therefore contain aliasing. Because of this aliasing, the high-frequency content of the desired reconstruction image is embedded in the low-frequency content of each of the observed images. Given a sufficient number of observation images, and if the set of observations vary in their phase (i.e. if the images of the scene are shifted by a sub-pixel amount), then the phase information can be used to separate the aliased high-frequency content from the true low-frequency content, and the full-resolution image can be accurate
Automated attendant
In telephony, an automated attendant (also auto attendant, auto-attendant, autoattendant, automatic phone menus, AA, or virtual receptionist) allows callers to be automatically transferred to an extension without the intervention of an operator/receptionist. Many AAs will also offer a simple menu system ("for sales, press 1, for service, press 2," etc.). An auto attendant may also allow a caller to reach a live operator by dialing a number, usually "0". Typically the auto attendant is included in a business's phone system such as a PBX, but some services allow businesses to use an AA without such a system. Modern AA services (which now overlap with more complicated interactive voice response or IVR systems) can route calls to mobile phones, VoIP virtual phones, other AAs/IVRs, or other locations using traditional land-line phones or voice message machines. == Feature description == Telephone callers will recognize an automated attendant system as one that greets calls incoming to an organization with a recorded greeting of the form, "Thank you for calling .... If you know your party's extension, you may dial it any time during this message." Callers who have a touch-tone (DTMF) phone can dial an extension number or, in most cases, wait for operator ("attendant") assistance. Since the telephone network does not transmit the DC signals from rotary dial telephones (except for audible clicks), callers who have rotary dial phones have to wait for assistance. On a purely technical level it could be argued that an automated attendant is a very simple kind of IVR however, in the telecom industry the terms IVR and auto attendant are generally considered distinct. An automated attendant serves a very specific purpose (replace live operator and route calls), whereas an IVR can perform all sorts of functions (telephone banking, account inquiries, etc.). An AA will often include a directory which will allow a caller to dial by name in order to find a user on a system. There is no standard format to these directories, and they can use combinations of first name, last name, or both. The following lists common routing steps that are components of an automated attendant: Transfer to extension Transfer to voicemail Play message (i.e., "our address is ...") Go to a sub-menu Repeat choices In addition, an automated attendant would be expected to have values for the following: '0' – where to go when the caller dials '0' Timeout – what to do if the caller does nothing (usually go to the same place as '0') Default mailbox – where to send calls if '0' is not answered (or is not pointing to a live person) == Background == PBXs (private branch exchanges) or PABXs (private automatic branch exchanges) are telephone systems that serve an organization that has many telephone extensions but fewer telephone lines (sometimes called "trunks") that connect that organization to the rest of the global telecommunications network. While persons within an enterprise served by a PBX can call each other by dialing their extension numbers, incoming calls, i.e., calls originating from a telephone not served by the PBX but intended for a party served by the PBX, required assistance from a switchboard operator (also called a "switchboard attendant") or a telephone service called DID ("direct inward dialing"). Direct inward dialing has advantages such as rapid connection to the destination party and disadvantages including cost, lack of identification of the called organization and use of ten-digit telephone numbers. Automated attendants provide, among many other things, a way for an external caller to be directed to an extension or department served by a PBX system without using direct inward dialing or without switchboard attendant assistance. == History == Automated attendants are not part of voicemail systems. Voice messaging (or voicemail or VM) technology has existed since the late 1970s; in the early 1980s companies provided voice-prompting systems that allowed callers to reach (route the call) to an intended party, not necessarily to leave a message. Automated attendant systems are also referred to as automated menu systems and much early work in this field was done by Michael J. Freeman, Ph.D. == Time-based routing == Many auto attendants will have options to allow for time-of-day routing, as well as weekend and holiday routing. The specifics of these features will depend entirely on the particular automated attendant, but typically there would be a normal greeting and routing steps that would take place during normal business hours, and a different greeting and routing for non-business hours.
KoalaPad
The KoalaPad is a graphics tablet, released in 1983 by US company Koala Technologies Corporation, for the Apple II, TRS-80 Color Computer (as the TRS-80 Touch Pad), Atari 8-bit computers, Commodore 64, and IBM PC compatibles. Originally designed by Dr. David Thornburg as a low-cost computer drawing tool for schools, the Koala Pad and the bundled drawing program, KoalaPainter, was popular with home users as well. KoalaPainter was called KoalaPaint in some versions for the Apple II, and PC Design for the IBM PC. A program called Graphics Exhibitor was included for creating slideshow presentations from KoalaPainter drawings. == Description == The pad was four inches square (i.e. roughly 10×10 cm) and mounted on a slightly inclined base with the back of the pad higher than the front. At the top, "behind" the pad, were two buttons. The pad hooked into the computer using the analog signals of the joystick ports (the so-called paddle inputs), which meant that it had a low resolution and tended to jostle the cursor if moved during use. As an alternative to the drawing stylus, the pad could as easily be operated by the user's fingers for tasks that demanded less precision, such as selecting between menu items (thus using the pad as a kind of "indirect touch screen"). The top-mounted buttons tended to be somewhat frustrating to use, as the user had to "reach around" the stylus to push the buttons in order to start or stop drawing. A similar tablet from Atari, the Atari CX77 Touch Tablet, addressed this with a built-in button on the stylus, which some enterprising users adapted for use with their KoalaPad. == KoalaPainter == The pad shipped with a simple bitmap graphics editor developed by Audio Light called KoalaPainter, PC Design or Micro Illustrator depending on the target machine (see release history). Although bundled with the pad, KoalaPainter could also be operated using an ordinary digital joystick. One unique feature of the program, for its time, was that it held two pictures in the computer's memory, allowing the user to flip from one to the other—a function commonly used in order to study the differences between an original and a modified picture, and to copy and paste between two different pictures. Some third-party bitmap editors could also be used with the KoalaPad, such as Broderbund's Dazzle Draw for the Apple II. === Release history === KoalaPainter for Commodore 64 (1983) and Atari 8-bit computers (1983) PC Design for the IBM PC (1983) Micro Illustrator for the Apple II (1983), Atari 8-bit computers (1983) and Commodore Plus/4 (1984) KoalaPainter II for Commodore 64 (1984) === Reception === Ahoy! called KoalaPainter "a very powerful and effective color drawing package", and concluded that it and the KoalaPad were "excellent in ease of use, a fine choice for a beginner as well as young children". BYTE's reviewer stated in December 1984 that he made far fewer errors when using an Apple Mouse with MousePaint than with a KoalaPad and its software. He found that MousePaint was easier to use and more efficient, predicting that the mouse would receive more software support than the pad. Cassie Stahl in InfoWorld's Essential Guide to Atari Computers praised the tablet and its documentation, rating it "Excellent" among all categories and stating that "Playing with the KoalaPad becomes addictive. It does everything it claims to, and it does it well". She also liked Micro Illustrator, rating it "Excellent" except for "Good" for Performance. While criticizing the limited erase function, Stahl reported an undocumented feature enabling exporting pictures to other software. === File format === The Commodore 64 version of KoalaPainter used a fairly simple file format corresponding directly to the way bitmapped graphics are handled on the computer: A two-byte load address, followed immediately by 8,000 bytes of raw bitmap data, 1,000 bytes of raw "Video Matrix" data, 1,000 bytes of raw "Color RAM" data, and a one-byte Background Color field. == KoalaWare == Koala Technologies offered more software beyond the bundled KoalaPainter and Graphics Exhibitor for use with the pad. Among these applications, marketed under the moniker KoalaWare (like KoalaPainter itself), was educational software for use with customized keypads and overlays, such as spelling tools, music programs, and mathematics instruction software, as well as software for "translating" graphical designs into Logo programs.
Art Recognition
Art Recognition is a Swiss technology company headquartered in Adliswil, within the Zurich metropolitan area, Switzerland. Art Recognition specializes in the application of artificial intelligence (AI) for art authentication and the detection of art forgeries. == Overview == Art Recognition was established in 2019 by Dr. Carina Popovici and Christiane Hoppe-Oehl. Art Recognition employs a combination of machine learning techniques, computer vision algorithms, and deep neural networks to assess the authenticity of artworks. The company's technology undergoes a process of data collection, dataset preparation, and training. === Academic partnerships and grants === Art Recognition has established a relationship with Innosuisse, a Swiss innovation agency, to expand its research and development initiatives. It has also formed a strategic collaboration with Nils Büttner, an art historian and professor at the State Academy of Fine Arts Stuttgart (ABK Stuttgart). === Notable developments === In May 2024, Art Recognition played a key role in identifying counterfeit artworks, including alleged Monets and Renoirs, being sold on eBay. Germann Auction in November 2024 became the first auction house to successfully conduct a sale of artwork authenticated entirely by artificial intelligence. As of January 2025, Art Recognition has appointed art crime expert and Pulitzer Prize finalist Noah Charney as an advisor. === Recognition and debates === The company was featured on the front page of The Wall Street Journal for its involvement in the authentication case of the Flaget Madonna, believed to have been partly painted by Raphael. A broadcast by the Swiss public television SRF covered how the algorithm can be used to detect art forgeries with high accuracy. The technology developed by Art Recognition has been recognized for its role in providing a technology-based art authentication solution, compared to traditional methods. == Controversial cases == Art Recognition's AI algorithm has been applied to several high-profile and controversial artworks, sparking significant interest and debate in the art world. Samson and Delilah at the National Gallery in London: The National Gallery's "Samson and Delilah", traditionally attributed to the artist Rubens, has also been examined using Art Recognition's AI, which has assessed the painting as non-authentic. De Brecy Tondo Madonna. A research team from Bradford University and the University of Nottingham initially attributed the painting to Raphael, employing an AI face recognition software, while the AI developed at Art Recognition returned a negative result. The Bradford group's AI was trained on 49 images, whereas Art Recognition employed a larger dataset of over 100 images. Lucian Freud Painting Controversy: Featured in The New Yorker, a painting attributed to Lucian Freud became a subject of dispute. Art Recognition's AI analysis played a big role in examining the painting's authenticity. Titian at Kunsthaus Zürich: A painting attributed to Titian, housed at Kunsthaus Zürich, has been a topic of debate among art experts. The application of Art Recognition's technology offered a new perspective. Following this debate, Kunsthaus Zürich has announced plans to initiate a comprehensive project aimed at resolving the authenticity questions surrounding the painting. Art Recognition has contributed to the authentication debate surrounding The Polish Rider, a painting traditionally attributed to Rembrandt but subject to scholarly debate.
Ordered dithering
Ordered dithering is any image dithering algorithm which uses a pre-set threshold map tiled across an image. It is commonly used to display a continuous image on a display of smaller color depth. For example, Microsoft Windows uses it in 16-color graphics modes. With the most common "Bayer" threshold map, the algorithm is characterized by noticeable crosshatch patterns in the result. == Threshold map == The algorithm reduces the number of colors by applying a threshold map M to the pixels displayed, causing some pixels to change color, depending on the distance of the original color from the available color entries in the reduced palette. The first threshold maps were designed by hand to minimise the perceptual difference between a grayscale image and its two-bit quantisation for up to a 4x4 matrix. An optimal threshold matrix is one that for any possible quantisation of color has the minimum possible texture so that the greatest impression of the underlying feature comes from the image being quantised. It can be proven that for matrices whose side length is a power of two there is an optimal threshold matrix. The map may be rotated or mirrored without affecting the effectiveness of the algorithm. This threshold map (for sides with length as power of two) is also known as a Bayer matrix or, when unscaled, an index matrix. For threshold maps whose dimensions are a power of two, the map can be generated recursively via: M 2 n = 1 ( 2 n ) 2 [ 4 M n 4 M n + 2 J n 4 M n + 3 J n 4 M n + J n ] = J 2 ⊗ M n + 1 n 2 M 2 ⊗ J n , {\displaystyle \mathbf {M} _{2n}={\frac {1}{(2n)^{2}}}{\begin{bmatrix}4\mathbf {M} _{n}&4\mathbf {M} _{n}+2\mathbf {J} _{n}\\4\mathbf {M} _{n}+3\mathbf {J} _{n}&4\mathbf {M} _{n}+\mathbf {J} _{n}\end{bmatrix}}=\mathbf {J} _{2}\otimes \mathbf {M} _{n}+{\frac {1}{n^{2}}}\mathbf {M} _{2}\otimes \mathbf {J} _{n},} where J n {\displaystyle \mathbf {J} _{n}} are n × n {\displaystyle n\times n} matrices of ones and ⊗ {\displaystyle \otimes } is the Kronecker product. While the metric for texture that Bayer proposed could be used to find optimal matrices for sizes that are not a power of two, such matrices are uncommon as no simple formula for finding them exists, and relatively small matrix sizes frequently give excellent practical results (especially when combined with other modifications to the dithering algorithm). This function can also be expressed using only bit arithmetic: M(i, j) = bit_reverse(bit_interleave(bitwise_xor(i, j), i)) / n ^ 2 == Pre-calculated threshold maps == Rather than storing the threshold map as a matrix of n {\displaystyle n} × n {\displaystyle n} integers from 0 to n 2 {\displaystyle n^{2}} , depending on the exact hardware used to perform the dithering, it may be beneficial to pre-calculate the thresholds of the map into a floating point format, rather than the traditional integer matrix format shown above. For this, the following formula can be used: Mpre(i,j) = Mint(i,j) / n^2 This generates a standard threshold matrix. for the 2×2 map: this creates the pre-calculated map: Additionally, normalizing the values to average out their sum to 0 (as done in the dithering algorithm shown below) can be done during pre-processing as well by subtracting 1⁄2 of the largest value from every value: Mpre(i,j) = Mint(i,j) / n^2 – 0.5 maxValue creating the pre-calculated map: == Algorithm == The ordered dithering algorithm renders the image normally, but for each pixel, it offsets its color value with a corresponding value from the threshold map according to its location, causing the pixel's value to be quantized to a different color if it exceeds the threshold. For most dithering purposes, it is sufficient to simply add the threshold value to every pixel (without performing normalization by subtracting 1⁄2), or equivalently, to compare the pixel's value to the threshold: if the brightness value of a pixel is less than the number in the corresponding cell of the matrix, plot that pixel black, otherwise, plot it white. This lack of normalization slightly increases the average brightness of the image, and causes almost-white pixels to not be dithered. This is not a problem when using a gray scale palette (or any palette where the relative color distances are (nearly) constant), and it is often even desired, since the human eye perceives differences in darker colors more accurately than lighter ones, however, it produces incorrect results especially when using a small or arbitrary palette, so proper normalization should be preferred. In other words, the algorithm performs the following transformation on each color c of every pixel: c ′ = n e a r e s t _ p a l e t t e _ c o l o r ( c + r × ( M ( x mod n , y mod n ) − 1 / 2 ) ) {\displaystyle c'=\mathrm {nearest\_palette\_color} {\mathopen {}}\left(c+r\times \left(M(x{\bmod {n}},y{\bmod {n}})-1/2\right){\mathclose {}}\right)} where M(i, j) is the threshold map on the i-th row and j-th column, c′ is the transformed color, and r is the amount of spread in color space. Assuming an RGB palette with 23N evenly distanced colors where each color (a triple of red, green and blue values) is represented by an octet from 0 to 255, one would typically choose r ≈ 255 N {\textstyle r\approx {\frac {255}{N}}} . (1⁄2 is again the normalizing term.) Because the algorithm operates on single pixels and has no conditional statements, it is very fast and suitable for real-time transformations. Additionally, because the location of the dithering patterns always stays the same relative to the display frame, it is less prone to jitter than error-diffusion methods, making it suitable for animations. Because the patterns are more repetitive than error-diffusion method, an image with ordered dithering compresses better. Ordered dithering is more suitable for line-art graphics as it will result in straighter lines and fewer anomalies. The values read from the threshold map should preferably scale into the same range as the minimal difference between distinct colors in the target palette. Equivalently, the size of the map selected should be equal to or larger than the ratio of source colors to target colors. For example, when quantizing a 24 bpp image to 15 bpp (256 colors per channel to 32 colors per channel), the smallest map one would choose would be 4×2, for the ratio of 8 (256:32). This allows expressing each distinct tone of the input with different dithering patterns. === A variable palette: pattern dithering === == Non-Bayer approaches == The above thresholding matrix approach describes the Bayer family of ordered dithering algorithms. A number of other algorithms are also known; they generally involve changes in the threshold matrix, which changes the distribution of the "noise" introduced by all kinds of dithering (the difference between the original image and the dithered image). === Halftone === Halftone dithering performs a form of clustered dithering, creating a look similar to halftone patterns, using a specially crafted matrix. === Void and cluster === The Void and cluster algorithm uses a pre-generated blue noise as the matrix for the dithering process. The blue noise matrix keeps the Bayer's good high frequency content, but with a more uniform coverage of all the frequencies involved shows a much lower amount of patterning. The "voids-and-cluster" method gets its name from the matrix generation procedure, where a black image with randomly initialized white pixels is gaussian-blurred to find the brightest and darkest parts, corresponding to voids and clusters. After a few swaps have evenly distributed the bright and dark parts, the pixels are numbered by importance. It takes significant computational resources to generate the blue noise matrix: on a modern computer a 64×64 matrix requires a couple seconds using the original algorithm. This algorithm can be extended to make animated dither masks which also consider the axis of time. This is done by running the algorithm in three dimensions and using a kernel which is a product of a two-dimensional gaussian kernel on the XY plane, and a one-dimensional Gaussian kernel on the Z axis. === Simulated Annealing === Simulated annealing can generate dither masks by starting with a flat histogram and swapping values to optimize a loss function. The loss function controls the spectral properties of the mask, allowing it to make blue noise or noise patterns meant to be filtered by specific filters. The algorithm can also be extended over time for animated dither masks with chosen temporal properties.
